Chapter 7
Multi-Layer Switching (MLS)
1 mac-vlan(s) configured for multi-layer switching:
mac 0010.a6a9.3470
vlan id(s)
10
router currently aware of following 1 switch(es):
switch id 00-e0-4e-2d-43-ef
RouterA#
Here is an example of the interface option:
RouterA#show mls rp interface fastethernet 4/0
mls active on FastEthernet4/0, domain test
interface FastEthernet4/0 is a management interface
RouterA#
These are the show commands, and as with any IOS, there are debugging
opportunities. Table 7.1 provides a summary of the debug commands avail-
able for MLS troubleshooting.
T A B L E 7 . 1
MLS Debug Command Summary
Command
Description
all
Performs all MLS debugging
error
Displays information on MLS errors
events
Displays information from MLS events
ip
Displays IP MLS events
locator
Displays MLS Locator information
packets
Displays information for all MLS packets
verbose packets
Displays information on all MLS verbose packets
