Hands-On Lab
241
Hands-On Lab
In this lab, you will configure a 5000 series switch, two 1900 switches,
and one 2621 router to provide ISL routing between VLANs.
This section will provide two labs:
Lab 6.1 External Inter-VLAN Routing
Lab 6.2 Internal Inter-VLAN Routing
In both of the labs, refer to Figure 6.3 for configuring inter-VLAN
communication.
F I G U R E 6 . 3
Configuring inter-VLAN communication for hands-on lab
Lab 6.1: External Inter-VLAN Routing
In this first lab, you'll configure the 2621 with ISL routing. You'll start with
configuring the two 1900 switches, then the 5000 switch, and then the 2621
router.
F0/0
172.16.1.1
2/1
2/2
1/2
1/1
F0/27
F0/26
F0/27
F0/26
e0/2
e0/2
e0/1
2/3
2621A
5000A
172.16.1.2
Si
HostA
172.16.1.5
HostB
172.16.2.2
HostC
172.16.3.2
1900B
172.16.1.4
1900A
172.16.1.3
