Chapter 3
VLANs
Remember that a created VLAN is unused until it is mapped to a switch port
or ports and that all ports are always in VLAN 1 unless set otherwise.
After you create the VLANs that you want, you use the show vlan com-
mand to see the configured VLANs. However, notice that, by default, all
ports on the switch are in VLAN 1. To change that, you need to go to each
interface and tell it what VLAN to be a part of:
1900EN#sh vlan
VLAN Name Status Ports
--------------------------------------
1 default Enabled 1-12, AUI, A, B
2 sales Enabled
3 marketing Enabled
4 mis Enabled
1002 fddi-default Suspended
1003 token-ring-defau Suspended
1004 fddinet-default Suspended
1005 trnet-default Suspended
--------------------------------------
VLAN Type SAID MTU Parent RingNo BridgeNo Stp Trans1 Trans2
---------------------------------------------------------------------------
1 Ethernet 100001 1500 0 0 0 Unkn 1002 1003
2 Ethernet 100002 1500 0 1 1 Unkn 0 0
3 Ethernet 100003 1500 0 1 1 Unkn 0 0
4 Ethernet 100004 1500 0 1 1 Unkn 0 0
1002 FDDI 101002 1500 0 0 0 Unkn 1 1003
1003 Token-Ring 101003 1500 1005 1 0 Unkn 1 1002
--More--
1004 FDDI-Net 101004 1500 0 0 1 IEEE 0 0
1005 Token-Ring-Net 101005 1500 0 0 1 IEEE 0 0
-------------------------------------------------------------------------
