Connecting and Logging In to a Switch
73
Todd5000> (enable) sh port 2/1
Port Name Status Vlan Level Duplex Speed Type
----- ------ --------- ---------- ---------- ------ --- ------
2/1 connect 1 normal auto auto 10/100BaseTX
The command show config displays the complete current configuration of the
set-based switch.
1900 IOS-Based Switch
The 1900 switch takes the type slot/port command with either the
interface
command or the show command. The interface command
allows you to set interface-specific configurations. The 1900 switch has only
one slot, zero (0):
Todd1900EN#config t
Enter configuration commands, one per line. End with
CNTL/Z
Todd1900EN(config)#int ethernet ?
<0-0> IEEE 802.3
Todd1900EN(config)#int ethernet 0?
/
Todd1900EN(config)#int ethernet 0/?
<1-25> IEEE 802.3
Todd1900EN(config)#int ethernet 0/1
Todd1900EN(config-if)#?
Interface configuration commands:
cdp Cdp interface subcommands
description Interface specific description
duplex Configure duplex operation
exit Exit from interface configuration mode
help Description of the interactive help system
no Negate a command or set its defaults
port Perform switch port configuration
shutdown Shutdown the selected interface
