692 Chapter 9: Scenarios for Final Preparation
I 170.1.8.0 [100/10539] via 170.1.12.1, 00:00:57, Serial0.1
I 170.1.14.0 [100/10476] via 170.1.12.1, 00:00:57, Serial0.1
C 170.1.12.0 is directly connected, Serial0.1
I 170.1.2.0 [100/8539] via 170.1.12.1, 00:00:57, Serial0.1
C 170.1.6.0 is directly connected, Ethernet0
I 170.1.4.0 [100/10539] via 170.1.12.1, 00:00:57, Serial0.1
R3#trace 170.1.9.4
Type escape sequence to abort.
Tracing the route to 170.1.9.4
1 170.1.12.1 40 msec 40 msec 44 msec
2 170.1.14.4 80 msec * 80 msec
R3#trace 170.1.5.2
Type escape sequence to abort.
Tracing the route to 170.1.5.2
1 170.1.12.1 40 msec 40 msec 40 msec
2 170.1.10.2 72 msec * 72 msec
R3#ping 170.1.5.2
Type escape sequence to abort.
Sending 5, 100-byte ICMP Echos to 170.1.5.2, timeout is 2 seconds:
!!!!!
Success rate is 100 percent (5/5), round-trip min/avg/max = 136/136/140 ms
R3#ping
Protocol [ip]:
Target IP address: 170.1.5.2
Repeat count [5]:
Datagram size [100]:
Timeout in seconds [2]:
Extended commands [n]: y
Source address or interface: 170.1.7.3
Type of service [0]:
Set DF bit in IP header? [no]:
Validate reply data? [no]:
Data pattern [0xABCD]:
Loose, Strict, Record, Timestamp, Verbose[none]:
Sweep range of sizes [n]:
Type escape sequence to abort.
Sending 5, 100-byte ICMP Echos to 170.1.5.2, timeout is 2 seconds:
UUUUU
Success rate is 0 percent (0/5)
R3#show frame-relay lmi
LMI Statistics for interface Serial0 (Frame Relay DTE) LMI TYPE = CISCO
Invalid Unnumbered info 0 Invalid Prot Disc 0
Example 9-21
Scenario 9-3c--R3 show and debug Output (Continued)
