Scenario 8-1: Point-to-Point Verification 611
199.1.1.0/27 is subnetted, 6 subnets
C 199.1.1.192 is directly connected, Serial0
I 199.1.1.128 [100/10476] via 199.1.1.161, 00:00:36, Serial1
[100/10476] via 199.1.1.193, 00:01:09, Serial0
C 199.1.1.160 is directly connected, Serial1
I 199.1.1.64 [100/8539] via 199.1.1.161, 00:00:36, Serial1
C 199.1.1.96 is directly connected, Ethernet0
I 199.1.1.32 [100/8539] via 199.1.1.193, 00:01:09, Serial0
Seville#show ipx route
Codes: C - Connected primary network, c - Connected secondary network
S - Static, F - Floating static, L - Local (internal), W - IPXWAN
R - RIP, E - EIGRP, N - NLSP, X - External, A - Aggregate
s - seconds, u - uses
6 Total IPX routes. Up to 1 parallel paths and 16 hops allowed.
No default route known.
C 1003 (SAP), E0
C 2002 (LAPB), Se1
C 2003 (HDLC), Se0
R 1001 [07/01] via 2003.0200.aaaa.aaaa, 2s, Se0
R 1002 [13/02] via 2003.0200.aaaa.aaaa, 2s, Se0
R 2001 [07/01] via 2003.0200.aaaa.aaaa, 2s, Se0
Seville#show interface serial 0 accounting
Serial0
Protocol Pkts In Chars In Pkts Out Chars Out
IP 44 3482 40 3512
IPX 46 3478 44 2710
CDP 21 6531 26 7694
Seville#debug lapb
LAPB link debugging is on
%LINK-3-UPDOWN: Interface Serial1, changed state to up
Serial1: LAPB O SABMSENT (2) SABM P
Serial1: LAPB I SABMSENT (2) UA F
Serial1: LAPB I CONNECT (104) IFRAME 0 0
Serial1: LAPB O CONNECT (76) IFRAME 0 1Serial1: LAPB I CONNECT (76) IFRAME 1 1
Serial1: LAPB O CONNECT (2) RR (R) 2
Seville#
Seville#ping 199.1.1.161
Type escape sequence to abort.
Sending 5, 100-byte ICMP Echos to 199.1.1.161, timeout is 2 seconds:
!!!!!
Success rate is 100 percent (5/5), round-trip min/avg/max = 8/8/12 ms
Seville#
Example 8-35
Seville Command Output, Scenario 8-1 (Continued)
continues
