Scenario 6-4: IPX Examination 437
IPXRIP: positing full update to 2012.ffff.ffff.ffff via Serial0 (broadcast)
IPXRIP: src=2012.0200.1111.1111, dst=2012.ffff.ffff.ffff, packet sent
network 1, hops 3, delay 8
network 2, hops 3, delay 8
network 1003, hops 2, delay 13
network 2013, hops 1, delay 7
network 1001, hops 1, delay 7
IPXRIP: positing full update to 2013.ffff.ffff.ffff via Serial1 (broadcast)
IPXRIP: src=2013.0200.1111.1111, dst=2013.ffff.ffff.ffff, packet sent
network 1, hops 3, delay 8
network 2, hops 3, delay 8
network 2023, hops 2, delay 13
network 1002, hops 2, delay 13
network 2012, hops 1, delay 7
network 1001, hops 1, delay 7
IPXRIP: update from 2012.0200.2222.2222
1003 in 2 hops, delay 13
2023 in 1 hops, delay 7
1002 in 1 hops, delay 7
Example 6-28
Yosemite Command Output, Scenario 6-4
Yosemite#show ipx route
Codes: C - Connected primary network, c - Connected secondary network
S - Static, F - Floating static, L - Local (internal), W - IPXWAN
R - RIP, E - EIGRP, N - NLSP, X - External, A - Aggregate
s - seconds, u - uses
8 Total IPX routes. Up to 1 parallel paths and 16 hops allowed.
No default route known.
C 1002 (SAP), To0
C 2012 (HDLC), Se0
C 2023 (HDLC), Se1
R 1 [08/03] via 2012.0200.1111.1111, 32s, Se0
R 2 [08/03] via 2012.0200.1111.1111, 33s, Se0
R 1001 [07/01] via 2012.0200.1111.1111, 33s, Se0
R 1003 [07/01] via 2023.0200.3333.3333, 32s, Se1
R 2013 [07/01] via 2012.0200.1111.1111, 33s, Se0
Yosemite#show ipx traffic
System Traffic for 0.0000.0000.0001 System-Name: Yosemite
Rcvd: 169 total, 0 format errors, 0 checksum errors, 0 bad hop count,
8 packets pitched, 161 local destination, 0 multicast
Bcast: 160 received, 242 sent
Sent: 243 generated, 0 forwarded
0 encapsulation failed, 0 no route
Example 6-27
Albuquerque Command Output, Scenario 6-4 (Continued)
continues
