406 Chapter 6: Routing
Example 6-21 shows the result of some RIP and SAP show and debug commands. (Do not
forget--the CCNA exam will ask questions about what commands can be used to view certain
details.)
Figure 6-15
IPX Network with Point-to-Point Serial Links
Example 6-21
Routing and SAP Information on Yosemite
Yosemite#show ipx route
Codes: C - Connected primary network, c - Connected secondary network
S - Static, F - Floating static, L - Local (internal), W - IPXWAN
R - RIP, E - EIGRP, N - NLSP, X - External, A - Aggregate
s - seconds, u - uses
7 Total IPX routes. Up to 1 parallel paths and 16 hops allowed.
No default route known.
C 2 (SAP), E0_
C 1012 (HDLC), Se0
C 1023 (HDLC), Se1
R 1 [07/01] via 1012.0000.aaaa.aaaa, 14s, Se0
Bugs
Sam
Emma
Elmer
Red
Daffy
Albuquerque
Node 0200.AAAA.AAAA
Seville
Node 0200.CCCC.CCCC
Yosemite
Node 0200.BBBB.BBBB
s1
s1
s1
s0
s0
s0
1
2
3
1023
1012
1013
Server 1
(Network 1001)
