Scenario 5-5: IPX Configuration
Assume the network setup in Figure 5-47.
Figure 5-47
Scenario 5-5 Network Diagram
Assuming the details established in Figure 5-47 for Scenario 5-5, complete or answer the
following:
1
Configure IPX on all three routers. Use the network numbers listed in the figure. (Do not
bother with IP.) Use point-to-point subinterfaces, and use the IPX node addresses shown
in the diagram on the serial interfaces.
2
You later find out that Beatrice is using NetWare's Ethernet_II encapsulation, Floyd is
using Ethernet_802.3, Barney is using Ethernet_802.2, and Governor is using
Ethernet_SNAP. Configure the changes necessary to support each client.
Andy
Barney
Governor
Opie
Mayberry
0200.1111.0000
Frame Relay
Full Mesh
s0
101
102
103
DLCI51
DLCI52
DLCI53
41
43
Server 2
Server 1
Server 3
Beatrice
Floyd
42
s0
Mount Pilot
0200.2222.0000
Raleigh
0200.3333.0000
s0
